Conector FPC de paso de 0.5mm con base en ambas caras de 8 pines.
| Item | Connector |
|---|---|
| Color | Natural |
| Max. Voltage | 250 V AC |
| Application | Signal |
| Series | FPC |
| Width | 0.2 in |
| Height | 2.05 mm |
| Length | 9.43 mm |
| Max. Temp. | 85 deg C |
| Hole Center to Center | 0.5 mm |
| Material | Liquid Crystal Polymer |
| Terminal Type | Surface Mount |
| Connection Material | Phosphor Bronze |
| Connector Type | Receptacle |
| Contact Plating Thickness | 0.025 µm |
| Contact Type | Socket |
| Current Rating | 0.5 A |
| Number of Rows | 1 |
| Terminal Finish | Gold Plated |
| Number of Contacts | 8 |
| Contact Finish | Gold Plated |
| Connector Terminates To | Flexible Printed Circuit |
| Package Quantity | 1 |
