zQSFP+ STACKED RECEPTACLE ASSEMBLY 2X1
| Item | Cage Assembly |
|---|---|
| Application | Signal |
| For Use With | QSFP MSA Compatible Transceiver; QSFP Cable Assembly |
| Includes | Lightpipe |
| Material | Nickel Silver |
| Contact Plating Thickness | 0.76 µm |
| Flammability Rating | UL 94 V-0 |
| Contact Finish | Gold Plated |
| Connector Terminates To | Printed Circuit Board |
| Number of Ports | 2 |
| Current Rating | 0.5 A |
| Hole Center to Center | 0.8 mm |
| Number of Contacts | 76 |
| Terminal Type | Through Hole - Press-Fit |
| Terminal Finish | Gold Plated |
| Max. Temp. | 85 deg C |
| Package Quantity | 1 |
