Perske Style Collet, SYOZ25, 1/2 in.
| Item | Collet |
|---|---|
| Collet Series | SYOZ25 |
| Range | 1/2 to 0.484 in |
| Size | 1/2" |
| Coolant Through | Yes |
| For Use With | SYOZ Collet Chuck Series |
| Coolant Fed | Coolant Through |
| Min. Size | 0.484 in |
| Max. Body Dia. | 1/2 in |
| Material - Machining | High Speed Steel |
| Measurement System | Inch |
| Number of Slots | 6 |
| Face Shape | Round |
| Overall Length | 52 mm |
| TIR Max. | 0 in |
| Collet Type | Perske |
| Head Dia. | 35 mm |
| Material | High-Carbon Steel |
| Bore Shape | Round |
| Finish | Precision Ground |
| Compatible Collet Chuck | SYOZ Collet Chucks |
| T.I.R. Tolerance | 0 in |
| Collapse Range - Maximum | 1/2 in |
| Standards | DIN 6388 |
| Outside Diameter - Maximum | 1.38 in |
| Package Quantity | 1 |
