26mm Long x 30mm Wide, IP65, IP67, IP69, For Use with OsiSense XM
| Pressure Sensor Size (psi) | 300 |
|---|---|
| For Use With | OsiSense XM |
| Electrical Connector Type | 4-pin M12 Male |
| Fluid Connector Type | 1/4"-18 NPT (male) |
| Display Type | No Display |
| Input Voltage | 12-24V DC |
| Output Signal (mA) | 4-20 |
| Electrical Circuit Type | Control Circuit |
| Ingress Protection Rating | IP65; IP69; IP67 |
| Resistance Features | Shock-Resistant; Vibration-Resistant |
| Maximum Operating Temperature (F) | 212 |
| Minimum Operating Temperature (F) | -22 |
| Overall Length (mm) | 26 |
| Overall Width/Diameter (mm) | 30 |
| Standards | EN/IEC 60947-1; CE; cULus; EN/IEC 60068; EN 61326; RoHS Compliant; EN/IEC 61000; DIN 40050; EN/IEC 60529 |
| UNSPSC Code | 39122210 |
| MSC Number | MSC# 54424007 |
