Interruptor de seguridad de 2 contactos NC, Nema 4, 4X, 12 IP 67.
| Item | Safety Interlock Switch |
|---|---|
| AC Contact Rating | 6 A @ 300 V |
| DC Contact Rating | 3 A @ 300 V |
| Solenoid Voltage | 120 V AC |
| IP Rating | IP67 |
| Standards | CSA, UL |
| Width | 4.33 in |
| Body Material | Plastic |
| Operating Force | 3.4 lb |
| Depth | 3.68 in |
| NEMA Rating | 12, 4, 4X |
| Contact Form | 2NC |
| Series | XCSTE |
| Conduit Size | 1/2 in NPT |
| Actuator Length | Key Dependent |
| Operating Temp. Range | -13 to 158 deg F |
| Description/Special Features | Dust Tight and Corrosion Resistant (Indoor/Outdoor) Enclosure, Water Tight |
| Height | 1.3 in |
| Connection Type | 1/2 in NPT Conduit |
| Style | Actuating Key, Solenoid Locking |
| Electrical Connection | 1/2 in NPT Conduit |
| Operating Temperature - Minimum | 9 deg F |
| Actuating Key Type | Pivoting, Flat |
| Overall Depth | 1.3 in |
| Circuitry Action | Slow Action |
| Operating Temperature - Maximum | 284 deg F |
| Resistance Properties | Corrosion Resistant, Dust Resistant, Shock Resistant, Vibration Resistant, Watertight |
| Manufacturer Warranty Length | 18 mo |
| NEMA Enclosure Rating | 12, 4, 4X |
| Overall Height | 3.67 in |
| Overall Width | 4.33 in |
| Actuator | Key |
| Electromagnet Interlocking | locking on de-energisation and unlocking on energisation of solenoid |
| Ambient Air Temperature For Operation | -13-140°F |
| Line Rated Current | 6 A |
| [Us] Rated Supply Voltage | 120 V |
| Device Short Name | XCSTE |
| Enclosure Material | Plastic |
| Number Of Poles | 2 |
| Enclosure Type | dust and damp proof enclosure indoor/outdoor || corrosion resistance enclosure indoor/outdoor |
| Permissible Voltage | 300 V AC |
| Nema Degree Of Protection | 12, NEMA 4/4X |
| Ip Degree Of Protection | IP67 |
| Contacts Type And Composition | 2 NC |
| Contact Operation | slow-break |
| Package Quantity | 1 |
