12 to 24 VDC Max, NPN & PNP, 4 Wires, 1,000 Hz
| Sensor Type | Inductive |
|---|---|
| Body Shape | Cylinder |
| Sensor Operation Output Mode | NO |
| Output Type | PNP; NPN |
| Connector Type | Four-Pin; Male; M12 |
| Detection Distance (mm) | 5.00 |
| Maximum Voltage | 12 - 24V DC |
| Overall Length (mm) | 70.00 |
| Ingress Protection Rating | IP67 |
| Maximum Load Capacity (mA) | 200 |
| Thread Size | M18x1 |
| Housing Material | Brass |
| Standards | CSA; UL; IEC 60529; RoHS Compliant |
| Number Of Wires | 4 |
| Response Frequency (Hz) | 1000 |
| UNSPSC Code | 39122230 |
| MSC Number | MSC# 56688526 |
