Sensor inductivo XSD 80x80x40 de plástico
| Proximity Sensor Style | Form 80 x 80 x 40 |
|---|---|
| Item | Inductive sensor XSD 80x80x40 - plastic |
| Proximity Sensing Method | Inductive |
| Proximity Sensor Power Requirement | 24V DC |
| Proximity Sensor Output Circuit Type | 4 to 20 mA; 3 Wire AC/DC |
| Length | 100 mm |
| Max. Detecting Distance | 60 mm |
| Width | 80 mm |
| Proximity Sensor Electrical Connection | Screw Clamp Terminal |
| Depth | 40 mm |
| Basic Proximity Sensor Case Material | Plastic |
| IP Rating | IP67 |
| Description/Special Features | Frontal Detection Face |
| Operating Temp. Range | -25 to 70 deg C |
| Standards | CE Marked |
| Application | General Purpose |
| Series | XSD |
| Switching Capacity | <= 20 mA |
| Body Type | fixed |
| Package Quantity | 1 |
