Piezas de interruptor de límite Telemecanique Sensors - ZCKM1H29. Encuentra repuestos de alta calidad para tu interruptor de límite.
| Item | Limit Switch Lever Arm |
|---|---|
| Height | 64-64 mm |
| Depth | 30 mm |
| Width | 64 mm |
| Ambient Air Temperature For Storage | -40-70°C |
| [Ie] Rated Operational Current | 3 A 240 V, AC-15, A300 EN/IEC 60947-5-1 appendix A || 0.27 A 250 V, DC-13, Q300 EN/IEC 60947-5-1 appendix A |
| Product Compatibility | XCKM |
| Maximum Resistance Across Terminals | 0.25 mOhm IEC 60255-7 category 3 |
| Number Of Steps | 1 1 position |
| Ambient Air Temperature For Operation | -25-70°C standard environment |
| Number Of Poles | 2 |
| Electrical Durability | 5000000 cycles, DC-13 120 V, 7 W 60 cyc/mn 0.5 IEC 60947-5-1 appendix C || 5000000 cycles, DC-13 24 V, 13 W 60 cyc/mn 0.5 IEC 60947-5-1 appendix C || 5000000 cycles, DC-13 48 V, 9 W 60 cyc/mn 0.5 IEC 60947-5-1 appendix C |
| Terminals Description Iso N°1 | (21-22)NC || (13-14)NO |
| Body Type | fixed |
| Positive Opening | with |
| Electrical Connection | screw-clamp terminals 1 x 0.34...2 x 1.5 mm² |
| Ip Degree Of Protection | IP66 |
| Product Or Component Type | limit switch body |
| Series Name | format |
| [Ithe] Conventional Enclosed Thermal Current | 10A |
| Contacts Type And Composition | 1 NC + 1 NO |
| Body Material | Metal |
| Short-Circuit Protection | 10 A cartridge fuse gG |
| Contact Operation | snap action |
| Device Short Name | ZCKM |
| Associated Head | ZCKD06 || ZCKD16 || ZCKD219 || ZCKD08 || ZCKD21 || ZCKD05 || ZCKD81 || ZCKD23 || ZCKD239 || ZCKD10 || ZCKD41 || ZCKD15 || ZCKD029 || ZCKD59 || ZCKD02 || ZCKD17 || ZCKD109 || ZCKD91 |
| [Ui] Rated Insulation Voltage | 500 V 3)IEC 60947-1 contact block || 300 VCSA C22.2 No 14 contact block || 300 VUL 508 contact block |
| Minimum Actuation Speed | 0.01 m/min |
| Cable Entry | 3 entries tapped for M20 x 1.5 cable gland |
| Contacts Material | silver plated contacts |
| Environmental Characteristic | standard environment |
| [Uimp] Rated Impulse Withstand Voltage | 6 kV IEC 60664 || 6 kV IEC 60947-1 |
| Ik Degree Of Protection | IK05 |
| Package Quantity | 1 |
