Interruptor de presión, (1) puerto, 1/4-18 pulgadas FNPT, SPDT, 1.5 a 75 psi, Acción estándar
| Item | Pressure Switch |
|---|---|
| Pressure Switch Port Type | (1) Port, 1/4-18 in FNPT |
| Pressure Switch Differential | 2.2 psi |
| Pressure Switch Range | 1.5 to 75 psi |
| Pressure Switch Electrical Contact Form | SPDT |
| Pressure Switch Action | Standard |
| Actuation Type | Nitrile Diaphragm |
| Differential | Fixed Differential Scale |
| NEMA Rating | NEMA 1 |
| Electrical Connection | Screw-Clamp Terminals |
| Temp. Range | -10 to 185°F |
| Max. Pressure | 240 psi |
| Circuit Type | Control Circuit |
| Standards | CSA C22.2 No 14; UL 508; UL listed file E12158 CCN NKPZ; CE; CSA LR25490 class 3211 03 |
| Housing Material | Thermoplastic |
| Type | Electromechanical Pressure Switch |
| Package Quantity | 1 |
