Interruptor de presión, (1) puerto, 1/4-18 pulgadas FNPT, SPDT, 20 a 1000 psi, Acción estándar.
| Item | Pressure Switch |
|---|---|
| Pressure Switch Port Type | (1) Port, 1/4-18 in FNPT |
| Pressure Switch Differential | 13 to 62 psi |
| Pressure Switch Range | 20 to 1,000 psi |
| Pressure Switch Electrical Contact Form | SPDT |
| Pressure Switch Action | Standard |
| Differential | Adjustable Differential Scale |
| NEMA Rating | NEMA 1 |
| Circuit Type | Control Circuit |
| Electrical Connection | Screw-Clamp Terminals |
| Housing Material | Thermoplastic |
| Standards | CE; CSA C22.2 No 14; UL listed file E12158 CCN NKPZ; UL listed file E12158 CCN NKPZ and CCN NTHT |
| Max. Pressure | 850 psi |
| Actuation Type | Nitrile Diaphragm |
| Temp. Range | -10 to 185°F |
| Type | Electromechanical Pressure Switch |
| Package Quantity | 1 |
