Interruptor de presión, (1) puerto, 1/4-18 pulgadas NPT hembra, SPDT, 20 a 1000 psi, acción estándar.
| Item | Pressure Switch |
|---|---|
| Pressure Switch Port Type | (1) Port, 1/4-18 in FNPT |
| Pressure Switch Differential | 49 to 150 psi |
| Pressure Switch Range | 20 to 1,000 psi |
| Pressure Switch Electrical Contact Form | SPDT |
| Pressure Switch Action | Standard |
| Max. Pressure | 10,000 psi |
| Circuit Type | Control Circuit |
| Housing Material | Thermoplastic |
| NEMA Rating | NEMA 1 |
| Temp. Range | -10 to 185°F |
| Standards | UL 508; CE; CSA LR25490 class 3211 03; UL listed file E12158 CCN NKPZ and CCN NTHT |
| Differential | Adjustable Differential Scale |
| Actuation Type | Piston |
| Electrical Connection | Screw-Clamp Terminals |
| Type | Electromechanical Pressure Switch |
| Package Quantity | 1 |
