Brazo de palanca de rodillo, brazo de 0.94 pulgadas.
| Item | Limit Switch Lever Arm |
|---|---|
| For Use With | Mfr. No. XCMD, XCKD, XCKP, XCKT |
| Roller Dia. | 0.63 in |
| Roller Material | Not Applicable |
| Roller Width | Not Applicable |
| Arm Width | 0.26 in |
| Actuator Type | Plunger |
| Roller Position | Not Applicable |
| Arm Length | 0.94 in |
| Arm Material | Metal |
| Arm Depth | 0.27 in |
| Standards | EU RoHS, REACH |
| Actuator Style | Plunger |
| Actuator Length | 0.94 in |
| Manufacturer Warranty Length | 18 mo |
| Operating Temperature - Minimum | -13 deg F |
| Roller Diameter | Not Applicable |
| Arm Length - Maximum | 0.94 in |
| Compatible with Series | XCKD, XCKP, XCKT, XCMD |
| Operating Temperature - Maximum | 158 deg F |
| Plunger Adjustability | Adjustable |
| Roller Adjustability | Not Applicable |
| Head Type | plunger head |
| Type Of Operator | end plunger spring return metal adjustable) |
| Associated Body | ZCP35 || ZCP29 || ZCT27N12 || ZCMD37L2 || ZCD37 || ZCMD81L5 || ZCMD25L1 || ZCP26 || ZCMD39L1 || ZCD31 || ZCD28 || ZCP39 || ZCMD61M12 || ZCMD81L2 || ZCT26P16 || ZCD21M12 || ZCP21 || ZCD26 || ZCMD21L08U78 || ZCP25 || ZCT25P16 || ZCP31 || ZCMD37L5 || ZCT28G11 || ZCT21G11 || ZCMD39L5 || ZCT25G11 || ZCD39 || ZCMD41L1 || ZCT21P16 || ZCP28 || ZCMD41L5 || ZCMD81L1 || ZCMD69C12 || ZCMD39L2 || ZCD25 || ZCP27 || ZCD29M12 || ZCT28N12 || ZCT26N12 || ZCMD25L5 || ZCMD21M12 || ZCMD21C12 || ZCD21 || ZCMD21L08R12 || ZCMD41L2 || ZCP29M12 || ZCT21N12 || ZCP37 || ZCMD61C12 || ZCMD25L2 || ZCT28P16 || ZCT26G11 || ZCMD21L1 || ZCMD29L1 || ZCMD21L5 || ZCMD37L1 || ZCD29 || ZCMD29C12 || ZCMD29L2 || ZCMD21L2 || ZCT27P16 || ZCD27 || ZCD35 || ZCMD29L5 || ZCP21M12 || ZCT25N12 || ZCT27G11 |
| Environmental Characteristic | standard environment |
| Ambient Air Temperature For Operation | -25-70°C |
| Product Or Component Type | limit switch head |
| Series Name | standard format |
| Positive Opening | with |
| Type Of Approach | vertical approach, 1 direction |
| Product Compatibility | XCKD || XCKP || XCMD || XCKT |
| Movement Of Operating Head | linear |
| Device Short Name | ZCE |
| Ambient Air Temperature For Storage | -40-70°C |
| Package Quantity | 1 |
