24 VDC Max, PNP, 4 Wires, 40 Hz
| Sensor Type | Ultrasonic |
|---|---|
| Body Shape | Cylinder; Flat |
| Sensor Operation Output Mode | NO |
| Output Type | PNP |
| Connector Type | Four-Pin; Male; M12 |
| Minimum Voltage | 12Vdc |
| Maximum Voltage | 24V DC |
| Overall Width (mm) | 18.00 |
| Sensor Head Size | M18 |
| Ingress Protection Rating | IP67 |
| Maximum Load Capacity (mA) | 100 |
| Overall Width/Diameter (mm) | 18 |
| Housing Material | Valox |
| Resistance Features | Shock-Resistant; Vibration-Resistant |
| Minimum Operating Temperature | 32 F |
| Standards | IEC 60068-2-6; UL; IEC 60529; cCSAus; IEC 60947-5-2; IEC 60068-2-27 |
| Number Of Wires | 4 |
| Response Frequency (Hz) | 40 |
| UNSPSC Code | 39122230 |
| undefined | undefined |
| MSC Number | MSC# 49922602 |
