Sonda de termopar, Tipo K, Longitud 12 pulgadas
| Item | Pipe Clamp Thermocouple |
|---|---|
| Grounded / Ungrounded | Grounded |
| Plug or Connector Type | Fork Terminal |
| Thermocouple Type | J |
| Insulation | Fiberglass |
| Error Accuracy (%) | +/-0.75 |
| Temp. Limit (Deg. F) | 900 |
| Error Accuracy (Deg. C) | +/-2.2 Below 293 Degrees |
| Thermocouple Element | 20 AWG |
| Lead Length | 12 ft |
| Construction | 7/8 to 1 1/2 in Dia Worm-drive Hose Clamp Attached to Thermocouple Wire |
| Connector Type | Spade Lugs |
| For Liquids and Gels | No |
| Maximum Temperature °F | 1,400 deg F |
| For Air | No |
| For Solids | Yes |
| Includes Thermowell | No |
| Sensor Type | Thermocouple |
| Maximum Temperature °C | 760 deg C |
| Temperature Range | 32 Degrees to 1,400 Degrees F/0 Degrees to 760 Degrees C |
| Cable Material | Fiberglass with Stainless Steel Braid |
| Maximum Wire Gauge | 0.25 mm |
| Cable Length | 12 ft |
| Junction Type | Grounded |
| For Gases | No |
| Minimum Temperature °F | 32 Degrees F |
| Accuracy | +/-2.2 Degrees C or +/-0.75% |
| For Surfaces | Yes |
| Process Mounting | Hose Clamp |
| Minimum Temperature °C | 0 Degrees C |
| Opening/Diameter | 7/8 in to 1 1/2 in |
| For Application | Appliances, Duct, Food and Beverage, HVAC, Ovens, Packaging, Pharmaceutical |
| Minimum Temperature °F | 32 Degrees F |
| Maximum Temperature °F | 1,400 deg F |
| Maximum Temperature °C | 760 deg C |
| Minimum Temperature °C | 0 Degrees C |
| Package Quantity | 1 |
