Temporizador eléctrico, riel Din, Astro, 24 horas/7 días, 2 canales.
| Item | Electronic Timer |
|---|---|
| Operation Mode | 7 days |
| Number of Channels | 2 |
| Contact Form | (2) SPDT |
| Voltage | 12/24V AC |
| Amps | 10 A |
| HP @ 120V | 2600W |
| Events Available - Electronic Timer | 56 |
| Available Actions - Electronic Timer | On/Off |
| Width | 1-1/2 in |
| Standards | VDE |
| Number of Pulse Events | 0 |
| Color | Gray |
| Display Width | 1 in |
| NEMA Rating | 1 |
| Height | 3-1/2 in |
| Min. Time Setting | 1 min |
| Depth | 2-3/4 in |
| Operating Temp. | -30 to 55 deg C |
| Max. Time Setting | 7 days |
| Event Allocation - Electronic Timer | 1 On/Off Action = 1 Event |
| Max. On/Off Cycles | 84 |
| Backup Time | 10 yr |
| Description/Special Features | Program with Zero Cross Switching and Self Prompting Programming and Astronomic Time Algorithm for Seasonal Time Adjustment |
| Display Height | 3/4 in |
| Mounting | Din Rail |
| Enclosure | Plastic |
| Backup Device | Battery |
| Number of Poles | 2 |
| Package Quantity | 1 |
