AC to DC Converter, 120V AC to 13.8V DC, 60 Hz
| Item | AC to DC Converter |
|---|---|
| Converts | 120V AC to 13.8V DC |
| Frequency | 60 Hz |
| Height | 3-3/4 in |
| Width | 6-1/2 in |
| Depth | 7-1/2 in |
| Type | Precision Regulated, 50% Duty Cycle |
| Input Voltage | 120 V AC |
| Input Frequency (Hz) | 60 Hz |
| Output Current (Amps) | 7 |
| Standards | RoHS |
| Output Voltage | 13.8 V DC |
| Peak Amps | 7 A |
| Manufacturers Warranty Length | 1 yr |
| Additional Information | Solid-State Integrated Circuit: Provides excellent voltage regulation to within ±0.5 V DC output voltage is maintained from 0 to 95% of full loadCrowbar Overvoltage Protection: Prevents overvoltage surges from damaging connected equipmentHigh Quality Filtering: Provides low-noise operation, excellent for sensitive communications receivers (.05 volts maximum ripple)Current-Limiting Electronic Foldback: Automatically limits current and voltage outputs incase of overloadHeavy-Duty Power Transformer: Provides complete line isolationLarge Heat Sinks and Vented Cabinet: Provides cool, continuous operation and long component life |
| TAA Compliant | Yes |
| Package Contents | PR 120VAC Power Adapter |
| Current Output - Maximum | 7 A |
| Interface | Not Applicable |
| Calibration Certificate Type | Not Certified |
| Digital Display Screen Type | LED |
| Input Voltage - Maximum | 120 V AC |
| Voltage Output - Maximum | 13.8 V |
| Package Quantity | 1 |
