Line Interactive UPS, 750VA, Line Interactive, Out: 110/115/120V AC In: 120V AC
| Item | Line Interactive UPS |
|---|---|
| UPS Type | Line Interactive |
| Power Rating | 750 VA |
| Mounting | Tower, Desktop |
| Wattage | 450 W |
| Input Voltage | 120V AC |
| Output Voltage | 110/115/120V AC |
| Backup Time (Half/Full Load) | 8.60 min/3 min |
| Outlet Type | (6) Surge; (6) UPS/Surge |
| Medical Grade | No |
| Number of Outlets | 12 |
| Hz | 60 Hz |
| Transfer Time | 1-4 milliseconds |
| NEMA Receptacle Configuration | 5-15R |
| Input Current | 12 A |
| Height | 4 in |
| Width | 7 in |
| Standards | TAA Compliant, UL1778 (USA), CSA (Canada), NOM (Mexico), Meets FCC Part 15 Category B (EMI) |
| Cord Length | 6 ft |
| NEMA Plug Configuration | 5-15P |
| Depth | 7 in |
| Battery Type | VRLA |
| Housing Material | ABS |
| Nominal Input Voltage(s) Supported | 120 V AC |
| Output Voltage Regulation (Line Mode) | 120V |
| Battery Access | Battery access door |
| UPS Dataline Suppression | 1 line TEL/DSL (1 in / 2 out) |
| Individually Controllable Load Banks | No |
| Half Load Runtime (min.) | 8 min 36 sec |
| Output Watt Capacity (Watts) | 450 |
| Communications Interface | USB (HID enabled) |
| DC System Voltage (VDC) | 12 |
| Nominal Output Voltage(s) Supported | 110 V, 115 V, 120 V |
| LED Indicators | 2 LEDs indicate power status and overload/check battery status |
| Battery Recharge Rate (Included Batteries) | 15.8 hours (10% to 90%) |
| Battery Replacement Description | Hot-swappable, user replaceable battery |
| UPS Power Module Dimensions (hwd, in.) | 4 x 12 x 7 |
| EMI / RFI AC Noise Suppression | Yes |
| UPS Certifications | Meets FCC Part 15 Category B (EMI); TAA Compliant; Tested to CSA (Canada); Tested to NOM (Mexico); Tested to UL1778 (USA) |
| Communications Cable | USB interface cable included |
| Output AC Waveform (Battery Mode) | PWM sine wave |
| Expandable Runtime | No |
| Cold Start (Startup in Battery Mode During a Power Failure) | Cold-start operation supported |
| Primary UPS Depth (mm) | 178 |
| UPS AC Suppression Response Time | Instantaneous |
| Output Volt Amp Capacity (VA) | 750 |
| Rated input current (Maximum Load) | 12 A |
| AC Mode Efficiency Rating (100% Load) | 0.98 |
| Primary UPS Height (mm) | 102 |
| Internal UPS Replacement Battery Cartridge | RBC51 |
| WatchDog Compatibility | Supports Watchdog application, OS and hard-reboot restart options for remote applications |
| High Voltage Transfer to Battery Power (Setpoint) | 147 |
| Full Load Runtime (min.) | 3 min |
| Relative Humidity | 0 to 95%, non-condensing |
| Operating Temperature Range | +32 to +104 degrees Fahrenheit / 0 to +40 degrees Celsius |
| Undervoltage Correction | Input voltages between 83 and 104 are boosted by 14% |
| Voltage Regulation Description | Automatic voltage regulation (AVR) maintains line power operation with an input voltage range of 83 to 147 |
| Output Voltage Regulation (Battery Mode) | +/- 5% |
| Storage Temperature Range | +5 to +122 degrees Fahrenheit / -15 to +50 degrees Celsius |
| High Availability UPS Features | Hot swappable batteries |
| Low Voltage Transfer to Battery Power (Setpoint) | 83 |
| AC Mode BTU / Hr. (Full Load) | 27 |
| Recommended Electrical Service | 15A 120V |
| Overvoltage Correction | Input voltages between 129 and 147 are reduced by 12% |
| Installation Form Factors Supported with Included Accessories | Tower; Ultra-compact desktop; Wallmount |
| UPS AC Suppression Joule Rating | 420 |
| PowerAlert Software | For local monitoring via the UPS™s built-in communication ports, download PowerAlert Local software at http://www.tripplite.com/poweralert |
| UPS Input Cord Length (ft.) | 6 |
| Grounding Lug | Includes |
| Input Phase | Single-Phase |
| Audible Alarm | Audible alarm indicates power-failure and overload status |
| Switches | Combination switch controls on/off power status and self-test operation |
| Primary Form Factor | Desktop |
| Maximum Operating Temperature | 104°F |
| Dataline Protection | RJ-11 |
| Surge Energy Rating | 420 J |
| Form Factor | Desktop, Wall Mountable |
| Product Series | AVR |
| Waveform Type | Pulse-width Modulated Sine Wave |
| Status Indicators | Power Status, Overload/check battery status |
| Software Included | PowerAlert Monitoring |
| Hot Swappable | Yes |
| Package Contents | AVR750UTAA 750VA Desktop UPS, USB Cable, Instruction Manual |
| Modem (RJ-11) | Yes |
| Alarm | Over Voltage, Power Failure |
| TAA Compliant | Yes |
| Protection Type | Brownout, EMI, RFI, Surge, Over Voltage, Black Out, Under Voltage, Transient, Lightning |
| Battery Management | User replaceable battery |
| USB | Yes |
| Load Capacity | 750 VA/450 W |
| Grounding Details | Yes |
| UPS Applications | Home/Office Desktop; Audio/Video; Retail/Point of Sale; Hospitality |
| Output Capacity (VA) | 750 |
| Package Includes | AVR750UTAA UPS System;USB cable;Instruction manual |
| Product Certifications | CSA (Canada); NOM (Mexico); UL 1778 |
| Product Compliance | FCC Part 15 Class B (USA); Trade Agreements Act (TAA) |
| Output Capacity (Watts) | 450 |
| Package Quantity | 1 |
