Outlet Strip, 15A, 4 Outlet, 10 ft.
| Item | Outlet Strip |
|---|---|
| Number of Outlets | 4 |
| Receptacle Configuration | Hospital Grade NEMA 5-15R |
| Plug Configuration | Hospital Grade NEMA 5-15P |
| Cord Length | 10 ft |
| Color | White |
| Gauge/Conductor | 14/3 |
| Standards | TUV tested to UL 1363A |
| Number of Power Switches | 0 |
| Includes | User Manual with Warranty Information |
| Housing Material | metal |
| Medical Facility Use | Patient Care - Only When Permanently Mounted (UL 1363A) |
| Cord Length - Ext. Cords and Outlet Strips | 10 ft |
| NEMA Plug Configuration | 5-15P-HG |
| Number of Total Outlets - Ext. Cords and Outlet Strips | 4 |
| NEC Cord Designation | SJT |
| Number of Outlet Rows | 1 |
| Amps | 15 |
| Height | 1-3/4 in |
| Medical Grade | Yes |
| NEMA Plug Configuration - Ext. Cords and Outlet Strips | 5-15P-HG |
| For Use With | Mobile Cart, Diagnostic Equipment, Instrument, IV Pole |
| Color - Ext. Cords and Outlet Strips | White |
| Plug Configuration - Ext. Cords and Power Strips | No Swivel, Straight |
| Length | 8-1/2 in |
| NEMA Receptacle Configuration | 5-15R-HG |
| Circuit Breaker | 600VAC FD |
| Voltage | 120V AC |
| Mounting Style | Keyhole |
| Power Indicator | No |
| Width | 2-1/2 in |
| Gauge/Conductor - Ext. Cords and Outlet Strips | 4.6667 |
| Max. Amps - Ext. Cords and Outlet Strips | 15 |
| Outlet Center Distance | 3 in |
| Number of Transformer Outlets | 2 |
| Max. Amps | 15 |
| Hz | 50/60 Hz |
| Depth | 1-1/2 in |
| Special Features | Coiled Cord |
| Wire Size | 14 AWG |
| Total Number of Outlets | 4 |
| Application | Healthcare Facility |
| Plug Style | Straight |
| Trade Designation | SJT |
| Number of Conductors | 3 |
| Length (Straight Wireway) | 8-35/64 in |
| Features | Anti-Microbial Protected, Integrated Keyhole Mounting Slots |
| Outlet Configuration | Single Row of 4 |
| Watts | 1800W |
| Product Type | Power Strip |
| Receptacles | 4 x NEMA 5-15R |
| Compatibility | Mobile Carts, IV Poles |
| Package Contents | PS-410-HG-OEMCC 4-Outlets Power Strip, Owner's Manual and Warranty Information |
| Maximum Frequency | 60 Hz |
| Plug/Connector Type | NEMA 5-15P |
| Input Voltage | 120 V AC |
| Maximum Input Current | 15 A |
| Product Name | PS-410-HG-OEMCC 4-Outlets Power Strip |
| Certifications & Standards | UL1363A |
| Input Cord Length (ft.) | 10 |
| Outlet Orientation | Single row of 4 |
| Transformer Accommodation | Yes |
| Built-In Circuit Breaker | Yes |
| Receptacle Color | White |
| Output Receptacles | 5-15R-HG |
| Voltage Compatibility (VAC) | 120 |
| Form Factors Supported | IV poles, mobile carts, crash carts and mobile medical workstations |
| Unit Dimensions (hwd / in.) | 1.73 x 2.5 x 8.54 |
| Overload Protection | 2 x 15amp breakers (1 line, 1 neutral) |
| Circuit Breaker (amps) | 15 |
| Product Compliance | NFPA 99: 10.2.3.6 |
| Right-Angle Plug | No |
| Nominal Input Voltage(s) Supported | 120 V AC |
| Product Certifications | UL 1363A |
| Recommended Electrical Service | 15A 120V |
| Antimicrobial | Yes |
| Input Plug Features | Coiled Hospital Grade Plug |
| Slot or Hole Mount Measurement (Center to Center) | Distance between keyhole tabs = 127mm; Distance between end tabs = 207.45mm |
| Input Cord Gauge Type | SJT, 14 gauge |
| Switches | No power switch |
| Outlets Measurement (Center to Center) | 3.05 in |
| Material of Construction | Metal |
| Power Cord Color | White |
| Package Includes | PS-410-HGOEMCC UL 1363A Medical-Grade Power Strip with four 15A Hospital-Grade Outlets and 3-ft. (0.91 m) Coiled, Extendable Cord;Owner's Manual with maintenance requirements |
| Input Plug Type | NEMA 5-15P-HG |
| Mounting Details | Includes flanges |
| Mounting Holes or Slots | Yes |
| Included Mounting Accessories | Mounting tabs and flanges |
| Frequency Compatibility | 50 / 60 Hz |
| Package Quantity | 1 |
