Power Inverter, Modified Sine Wave, 6,000 W Peak, 3,000 W Continuous, 4 Outlets
| Item | Power Inverter |
|---|---|
| Peak Output Power | 6,000 W |
| Continuous Output Power | 3,000 W |
| Inverter Output Form | Modified Sine Wave |
| Inverter Input Voltage | 12V DC |
| Inverter Output Voltage | 120V AC |
| Outlet Type | GFCI |
| DC Connection | Input Terminals |
| Number of Outlets | 4 |
| Nominal Output Power | 3,000 W |
| Width | 12-1/2 in |
| Includes | 25 ft Remote Cable, Remote Control LED/Switch Module (APSRM4) |
| Height | 4.3 in |
| Depth | 14.8 in |
| Case Material | Aluminum, Sheet Metal |
| Standards | OSHA 1926.404 (b) (ii) |
| Max. Input Current | Full continuous load - 286 A at 12V DC; No load - 2.6 A at 12V DC; Shutdown / load sense mode - less than 500 mA |
| Application | Coffee Makers, DVD Players, Game Systems, Microwaves, Office Equipment, Power Tools, TVs |
| Temp. Range | 32°F to 104°F |
| Features | Battery Charge Level LED, Connected Load Level LEDs, Daisy-Chain Capability, Dual Connections, Grooved Cooling Surface, Low Voltage Alarm/Shutdown, Operating Mode Switch Controls Inverter Operation, Remote Control LED/Switch Module |
| Overall Width | 12-1/2 in |
| Overall Height | 4-1/4 in |
| Inveter Output Voltage | 120V |
| Output Frequency | 60 Hz |
| Minimum Operating Temperature | 32 deg F |
| Inverter DxWxH | 14-3/4 in x 12-1/2 in x 4-1/4 in |
| NEMA Rating | NEMA 5-15R |
| Fused | Yes |
| Input Current | 286 A at 12V DC, 2.6 A at 12V DC, Less Than 500 mA |
| Output Form | Modified Sine Wave |
| Maximum Operating Temperature | 104 deg F |
| Type of Indicator | LED |
| Input Connection | Input Terminals |
| Output Connection | (4) NEMA 5-15R |
| Overall Depth | 14-3/4 in |
| Input Voltage | 12V DC |
| Output Voltage | 120 V AC |
| Maximum Frequency | 60 Hz |
| Product Line | PowerVerter |
| Product Color | Gray |
| Product Name | PowerVerter PV3000GFCI DC-to-AC Power Inverter |
| Package Contents | PowerVerter PV3000GFCI DC-to-AC Power Inverter, Remote Control LED/Switch Module, 25-ft. Remote Cable, Instruction Manual |
| Audible Alarm | Dual function alarm indicates overload conditions or low DC input voltage of 10.5V or less. |
| Output Receptacles | 5-15R |
| Form Factors Supported | Mounting slots enable permanent placement of inverter on any horizontal surface |
| Operating Temperature | 32 to 104 F (0 to 40 C) |
| Frequency Compatibility | 60 Hz |
| Input Cord Length Details | User supplies cabling. Minimum gauges for full load operation: 0 (10 ft max), 00 or 2/0 (13 ft max), Twin 00 using 4 conductors (26 ft) |
| Nominal Output Voltage(s) Supported | 120 V |
| Output Voltage Regulation | Maintains PWM sine wave output voltage of 115 VAC (+/- 8 VAC) |
| Output Frequency Regulation | 60 Hz (+/- 3 Hz) |
| Package Includes | PV3000GFCI Inverter;Remote control LED/switch module (APSRM4);25-ft. (7.62 m) remote cable;Warranty information;Instruction manual |
| Overload Protection | Automatic overload protection shuts down inverter system in the event of overloads. Output is protected by 2 built-in 20A circuit breakers (each controlling power to 2 outlets). Inverter and electrical system are further protected via set of 6 40A automotive input fuses. |
| Voltage Compatibility (VDC) | 12 |
| DC System Voltage (VDC) | 12 |
| Recommended Electrical Service | Requires 12VDC input source capable of delivering 286A for the required duration (when used at full capacity). For automotive applications, professional hardwire installation with 500A battery system fusing is recommended. |
| Material of Construction | Aluminum, Steel |
| Grounding | Grounding lug grounds the inverter to vehicle or earth ground - user supplies cabling |
| Maximum Input Amps | 286 |
| Switches | 3 position rocker switch enables on/off power control, plus remote setting which enables inverter to be remotely powered on or off when used in conjunction with included APSRM4 module. |
| Relative Humidity | 0%-95% Non-Condensing |
| Package Quantity | 1 |
