Prewired Raceway, 20A, 12 Outlet, Beige
| Item | Power Strip |
|---|---|
| Number of Outlets | 12 |
| Color | Beige |
| Standards | cUL Listed, UL Listed |
| Receptacle Type | NEMA 5-20R |
| Outlet Center Distance | 3 in |
| Material | Metallic |
| Number of Circuits | 1 |
| Series | PS3612 |
| Length | 3 ft |
| Mounting Style | Keyhole |
| Includes | (1) Instruction Manual |
| Amps | 20 |
| Housing Material | Metal |
| Max. Amps | 20 |
| NEMA Plug Configuration | NEMA 5-15/20R |
| Height | 1-1/2 in |
| Number of Transformer Outlets | 6 |
| Width | 1-1/2 in |
| NEMA Receptacle Configuration | NEMA 5-15R, NEMA 5-15/20R |
| Hz | 50/60 Hz |
| Voltage | 120VAC |
| Depth | 36 in |
| Frequency | 50/60 Hz |
| Length (Straight Wireway) | 3 ft |
| Optional Entrance Fitting | Conduit Fitting |
| Watts | 2400W |
| Product Name | Power Strip 120V AC |
| Additional Information | Input connection type: 3/4 inch knockouts support hardwire input connection, Integrated keyhole mounting tabs: Mount through housing supports bolt down installation to a variety of flat surfaces |
| Package Contents | Power Strip 120V AC, PS3612-20HW, Instruction manual |
| Receptacles Spacing | 2.99 in |
| Certifications & Standards | UL, cUL |
| Receptacles | 2 x NEMA 5-20R, 10 x NEMA 5-15R |
| Mount Type | Vertical, Horizontal |
| Power Rating | 2,400 W |
| Maximum Input Current | 20 A |
| Input Voltage | 120 V AC |
| Maximum Frequency | 60 Hz |
| Maximum Output Voltage | 120 V AC |
| Product Type | Power Strip |
| Plug/Connector Type | Hardwired |
| Product Color | Beige, Almond |
| Voltage Compatibility (VAC) | 120 |
| Package Includes | PS3612-20HW;Instruction manual |
| Transformer Accommodation | Yes |
| Product Certifications | cUL Listed; UL Listed |
| Output Receptacles | 5-15/20R; 5-15R |
| Outlet Spacing | 2.99 in |
| Receptacle Color | Beige |
| Right-Angle Plug | No |
| Frequency Compatibility | 50 / 60 Hz |
| Input Plug Type | Hard-wire |
| Material of Construction | Metal |
| Unit Dimensions (hwd / in.) | 1.5 x 1.5 x 36 |
| Mounting Holes or Slots | No |
| Built-In Circuit Breaker | Yes |
| Circuit Breaker (amps) | 20 |
| Outlets Measurement (Center to Center) | 4 in |
| Recommended Electrical Service | 20A 120V |
| Housing Color | Beige |
| Nominal Input Voltage(s) Supported | 120 V AC |
| Package Quantity | 1 |
