Smart UPS, 350VA, Line Interactive, Out: 230V AC In: 220V AC
| Item | Smart UPS |
|---|---|
| UPS Type | Line Interactive |
| Power Rating | 350 VA |
| Mounting | Tower |
| Wattage | 225 W |
| Input Voltage | 220V AC |
| Output Voltage | 230V AC |
| Backup Time (Half/Full Load) | 37 min/15.50 min |
| Number of Outlets | 6 |
| Height | 10.6 in |
| Standards | Tested to CE/ IEC 60601-1 (Series AGOM6832), Class B (emissions) |
| Width | 7.4 in |
| Depth | 7.4 in |
| NEMA Plug Configuration | C14 |
| NEMA Receptacle Configuration | C13 |
| Transfer Time | 5 milliseconds AC to battery; 8 milliseconds battery to AC |
| Input Current | 1.8 A |
| Hz | 50/60 Hz |
| Housing Material | PVC |
| AC Mode BTU / Hr. (Full Load) | 15.6 |
| Individually Controllable Load Banks | No |
| AC Suppression Response Time | Instantaneous |
| Audible Alarm | Audible alarm indicates power failure conditions, silenceable via alarm cancel switch. Once cancelled, alarm will resume when approximately 2 minutes of battery operation remain (assuming full load) |
| Cold Start (Startup in Battery Mode During a Power Failure) | Cold-start operation supported |
| Grounding Lug | Ground Potential Equalization Connector: POAG-S6/20 |
| Output AC Waveform (Battery Mode) | PWM sine wave |
| Battery Access | Battery access door allows hot swap battery replacement without powering connected equipment off |
| Frequency Compatibility Details | Automatic frequency selection |
| Switches | Yes, includes 2 front panel mounted push-button switches for system enable, self-test and alarm cancel functions |
| UPS Input Connection Description | C14 inlet accepts user-supplied AC power cord with grounded country-specific plug |
| Recommended Electrical Service | 10A 230V |
| Battery Mode BTU / Hr. (Full Load) | 124.5 |
| Output Watt Capacity (Watts) | 225 |
| Dataline Suppression | 2-Line Tel/DSL |
| Operating Temperature Range | +32 to +104 degrees Fahrenheit / 0 to +40 degrees Celsius |
| Battery Recharge Rate (Included Batteries) | Less than 7.2 hours from 10% to 90% |
| UPS Input Cord Length (ft.) | 0.5 |
| High Voltage Transfer to Battery Power (Setpoint) | 266 |
| Expandable Runtime | No |
| Primary Form Factor | Tower |
| Primary UPS Height (mm) | 269 |
| Primary UPS Depth (mm) | 188 |
| Voltage Regulation Description | Line interactive UPS offers a single boost level of brownout correction to maintain usable, computer grade output |
| UPS Power Module Dimensions (hwd, in.) | 10.6 x 5.2 x 7.4 |
| Installation Form Factors Supported with Included Accessories | Tower |
| Output Voltage Regulation (Line Mode) | -18% +8% |
| Voltage Compatibility (VAC) | 230 |
| Relative Humidity | 0 to 95%, non-condensing |
| UPS Certifications | CE; Tested to UL60601-1 (medical grade) |
| Low Voltage Transfer to Battery Power (Setpoint) | 159 |
| LED Indicators | 4 LEDs indicate line power, battery power, overload and battery low/replace status |
| EMI / RFI AC Noise Suppression | Yes |
| Undervoltage Correction | Input voltages between 159 and 199 are boosted by 14% |
| DC System Voltage (VDC) | 12 |
| Nominal Input Voltage(s) Supported | 230 V AC |
| Communications Interface | USB |
| Full Load Runtime (min.) | 15 min 30 sec |
| Input Phase | Single-Phase |
| Installation Form Factors Supported with Optional Accessories | Wallmount (UPSWM - tower mounting kit) |
| Half Load Runtime (min.) | 37 min |
| Output Volt Amp Capacity (VA) | 350 |
| Cooling Method | Convection |
| Nominal Output Voltage(s) Supported | 220 V, 230 V, 240 V |
| Storage Temperature Range | +5 to +122 degrees Fahrenheit / -15 to +50 degrees Celsius |
| Rated input current (Maximum Load) | 1.8 A |
| Internal UPS Replacement Battery Cartridge | RBC52 (quantity 2) |
| Battery Life | 6 yr |
| Additional Information | Input Receptacle: C14, Output Receptacles: 6 x C13 |
| Package Contents | OmniSmart OMNIX350HG 350VA Tower UPS, USB Cables, Telephone Cable, Warranty Information, Instruction Manual |
| Form Factor | Tower |
| Hot Swappable | Yes |
| USB | Yes |
| Load Capacity | 350 VA/225 W |
| Typical Battery Recharge Time | 7 hr 12 min |
| Package Quantity | 1 |
