Smart UPS, 750VA, Line Interactive, Out: 110/115/120V AC In: 120V AC
| Item | Smart UPS |
|---|---|
| VA Rating - UPS Systems | 750 VA |
| UPS Type | Line Interactive |
| Power Rating | 750 VA |
| Mounting | Tower, Wall |
| Wattage | 450 W |
| Input Voltage | 120V AC |
| Output Voltage | 110/115/120V AC |
| Backup Time (Half/Full Load) | 8.3 min/2.2 min |
| Outlet Type | (3) Surge; (3) UPS/Surge |
| Medical Grade | No |
| Number of Outlets | 6 |
| Input Current | 12 A |
| Ports | USB (HID enabled) |
| Includes | USB and Telephone Interconnection Cables |
| Transfer Time | 2 to 4 msec |
| NEMA Plug Configuration | 5-15P |
| Height | 11 in |
| Phase | Single |
| Width | 8 in |
| Footnotes | 4,6 |
| Hz | 60 Hz |
| NEMA Receptacle Configuration | 5-15R |
| Cord Length | 6 ft |
| Fax/Modem Line Protection | Yes |
| Special Features | Advanced AVR Corrects Brownouts and Overvoltages, Pure Sine Wave Output |
| Standards | CSA (Canada), FCC Part 15 Class B (USA), NOM (Mexico), RoHS, UL1778 |
| Automatic Volts Regulation | Yes |
| Display Type | LED |
| Depth | 8 in |
| Voltage | 120 |
| Overall Width | 5.2 in |
| Capacity - Batteries | 750 VA/450 W |
| Battery Type | Sealed Lead Acid |
| Operating Temp. Range | 122°F (50°C) |
| Housing Color | Black |
| Input Connection | 6 ft Cord with NEMA 5-15P Plug |
| Housing Material | PVC |
| EMI / RFI AC Noise Suppression | Yes |
| Low Voltage Transfer to Battery Power (Setpoint) | 89 |
| Battery Replacement Description | Hot-swappable, user replaceable batteries |
| Rated input current (Maximum Load) | 12 A |
| AC Mode BTU / Hr. (Full Load) | 38 |
| Primary UPS Depth (mm) | 191 |
| WatchDog Compatibility | Supports Watchdog application, OS and hard-reboot restart options for remote applications |
| Expandable Runtime | No |
| UPS Dataline Suppression | 1 line TEL/DSL (1 in / 1 out); 10/100Base T Ethernet |
| Undervoltage Correction | Input voltages between 89 and 104 are boosted by 14% |
| Communications Interface | USB (HID enabled) |
| Internal UPS Replacement Battery Cartridge | RBC51 |
| Output AC Waveform (Battery Mode) | PWM sine wave |
| UPS AC Suppression Response Time | Instantaneous |
| Voltage Regulation Description | Automatic voltage regulation (AVR) maintains line power operation with input voltage as low as 89 |
| High Voltage Transfer to Battery Power (Setpoint) | 139 |
| Battery Recharge Rate (Included Batteries) | Less than 4.5 hours from 10% to 90% |
| Input Phase | Single-Phase |
| AC Mode Efficiency Rating (100% Load) | 0.97 |
| UPS Certifications | Tested to UL1778 (USA); Tested to CSA (Canada); Tested to NOM (Mexico); Meets FCC Part 15 Category B (EMI) |
| PowerAlert Software | For local monitoring via the UPSâ„¢s built-in USB port, download PowerAlert Local software at http://www.tripplite.com/poweralert |
| Output Volt Amp Capacity (VA) | 750 |
| Installation Form Factors Supported with Optional Accessories | Wallmount ( UPSWM - tower mounting kit) |
| UPS Power Module Dimensions (hwd, in.) | 10.8 x 5.2 x 7.5 |
| Battery Access | Battery access door |
| Nominal Input Voltage(s) Supported | 120 V AC |
| Storage Temperature Range | +5 to +122 degrees Fahrenheit / -15 to +50 degrees Celsius |
| Relative Humidity | 0 to 95%, non-condensing |
| Installation Form Factors Supported with Included Accessories | Tower |
| LED Indicators | 4 LEDs indicate line power, battery power, overload and battery low/replace status |
| Full Load Runtime (min.) | 2 min 12 sec |
| Operating Temperature Range | +32 to +104 degrees Fahrenheit / 0 to +40 degrees Celsius |
| DC System Voltage (VDC) | 12 |
| Alarm Cancel Operation | Power-fail alarm can be silenced using alarm-cancel switch; once silenced, alarm will re-sound to indicate low-battery status |
| Half Load Runtime (min.) | 8 min 18 sec |
| Cold Start (Startup in Battery Mode During a Power Failure) | Cold-start operation supported |
| Nominal Output Voltage(s) Supported | 110 V, 115 V, 120 V |
| Primary Form Factor | Tower |
| UPS AC Suppression Joule Rating | 510 |
| Output Watt Capacity (Watts) | 450 |
| UPS Input Cord Length (ft.) | 6 |
| Switches | 2 Switches control off/on power status and alarm-cancel/self-test operation |
| Audible Alarm | Audible alarm indicates power-failure and low-battery conditions |
| Output Voltage Regulation (Battery Mode) | +/- 5% |
| Individually Controllable Load Banks | No |
| Primary UPS Height (mm) | 274 |
| Recommended Electrical Service | 15A 120V |
| Communications Cable | USB interface cable included |
| Battery Mode BTU / Hr. (Full Load) | 512 |
| High Availability UPS Features | Hot swappable batteries |
| Battery Life | 6 yr |
| Maximum Operating Temperature | 122°F |
| Dataline Protection | RJ-45 |
| Status Indicators | 4 LEDs indicate performance conditions: GREEN "online" / GREEN "voltage regulation enabled" / RED "on battery" / YELLOW "battery low/replace" |
| Assembly Required | No |
| Typical Battery Recharge Time | 4 hr |
| Protection Type | Surge |
| Alarm | On Battery |
| Additional Information | SMART750USB line-interactive UPS system offers extended voltage regulation (AVR) and battery support as well as complete AC and dialup/DSL/ethernet line surge suppression, Supports entry level PC systems for up to 45 minutes during power failures to enable a safe system shutdown, Supports a max load of 750VA/450 watts for 5 minutes and a half load of 375VA/225 watts for 17 minutes, Automatic Voltage Regulation (AVR) circuits correct brownouts as low as 83 volts without using battery power, Attractive black tower configuration, Includes 3 battery-supported outlets, plus 3 additional surge-only outlets, 6 foot AC line cord (all NEMA 5-15), USB port enables unattended shutdown without data loss during extended power failures; includes USB cable, Built-in USB port supports on battery, low battery, power restored, AC line voltage, DC battery voltage and battery capacity messaging; interface supports timed inverter shutoff after unattended shutdown, activate self-test and 10 second reboot of connected equipment, PowerAlert UPS monitoring and unattended shutdown software available via free download from www.tripplite.com, Supports Tripp Lite's WatchDog software application to restore unresponsive programs by automatically restarting them and rebooting completely locked computers by automatically switching UPS power off and back on again (part #WATCHDOGSW), Built-in dataline suppression jacks protect a single dialup phone / DSL line or network Ethernet line connection, Built-in audible alarm and 4 front panel LEDs indicate UPS system and line power status, 750VA / 450 watt power handling ability supports a variety of computer, internetworking, telecom and consumer electronics equipment, Supports battery replacement via built-in access panel, Compatible with 120V / 60Hz applications for USA, Canada, Mexico and more, 2 year manufacturer's warranty, $200,000 Ultimate Lifetime Insurance (USA & Canada Only) |
| Package Contents | SMART750USB Standby UPS System, USB and telephone interconnection cables, Instruction manual with warranty information |
| USB | Yes |
| Surge Energy Rating | 510 J |
| Load Capacity | 750 VA/450 W |
| Waveform Type | Pulse-width Modulated Sine Wave |
| Form Factor | Tower |
| Software Included | PowerAlert Software |
| Output Capacity (Watts) | 450 |
| Product Certifications | CSA (Canada); NOM (Mexico); UL 1778 |
| Product Compliance | FCC Part 15 Class B (USA) |
| UPS Applications | Home/Office Desktop; Retail/Point of Sale; Hospitality |
| Output Capacity (VA) | 750 |
| Package Includes | SMART750USB line interactive UPS System;USB and telephone interconnection cables;Instruction manual with warranty information |
| Output Ports Included | USB |
| Input Current - Maximum | 12 A |
| Surge Suppression Rating | 510 J |
| Automatic Voltage Regulation | Includes Automatic Voltage Regulation |
| Manufacturer Warranty | 2 yr, 3 yr (Registration) |
| Audible Alarm Conditions | Low Battery, Power Outage |
| External Battery Compatible | Not External Battery Pack Compatible |
| Power Cord Length | 6 ft |
| Battery Recharge Time | 4 hr 30 min |
| Includes Battery | Battery Included |
| Power Rating - Real | 450 W |
| Data Line Protection | Includes Data Line Surge Protection |
| Operating Temperature - Minimum | 32 deg F |
| Operating Temperature - Maximum | 104 deg F |
| Package Quantity | 1 |
