UPS System, 350VA, Standby, Out: 110/115/120V AC In: 120V AC
| Item | UPS System |
|---|---|
| VA Rating - UPS Systems | 350 VA |
| UPS Type | Standby |
| Power Rating | 350 VA |
| Mounting | Tower, Desktop |
| Wattage | 210 W |
| Input Voltage | 120V AC |
| Output Voltage | 110/115/120V AC |
| Backup Time (Half/Full Load) | 7 min/2 min |
| Outlet Type | (3) Surge; (3) UPS/Surge |
| Medical Grade | No |
| Number of Outlets | 6 |
| Ports | DB9, TEL/DSL |
| Hz | 60 Hz |
| Green Environmental Attribute | Product Contributes To Reducing Energy Consumption |
| NEMA Plug Configuration | 5-15P |
| Cord Length | 6 ft |
| Input Current | 12 A |
| Includes | Interface Cable |
| Phase | Single |
| Footnotes | DB9 and TEL/DSL |
| Special Features | Cold Start Operation Supported |
| Standards | CSA, CSA-C22.2 No. 107.3, FCC Part 15 Class B, NOM, RoHS, UL1778 |
| Height | 3 in |
| Display Type | No Display |
| Transfer Time | 2 to 4 msec |
| Automatic Volts Regulation | No |
| NEMA Receptacle Configuration | 5-15R |
| Fax/Modem Line Protection | Yes |
| Depth | 5 in |
| Width | 5 in |
| Overall Width | 4.33 in |
| Operating Temp. Range | 122°F (50°C) |
| Housing Color | Black |
| Battery Type | Sealed Lead Acid |
| Capacity - Batteries | 350 VA/180 W |
| Input Connection | NEMA 5-15P Plug |
| Housing Material | ABS |
| Nominal Input Voltage(s) Supported | 120 V AC |
| Individually Controllable Load Banks | No |
| High Availability UPS Features | Battery Independent Restart |
| Expandable Runtime | No |
| Low Voltage Transfer to Battery Power (Setpoint) | 95 |
| Communications Interface | DB9 Serial |
| UPS AC Suppression Joule Rating | 316 |
| AC Mode BTU / Hr. (Full Load) | 13.1 |
| Output Voltage Regulation (Line Mode) | 120V |
| Primary UPS Height (mm) | 105 |
| Recommended Electrical Service | 15A 120V |
| PowerAlert Software | For local monitoring via the UPSâ„¢s built-in communication ports, download PowerAlert Local software at http://www.tripplite.com/poweralert |
| Half Load Runtime (min.) | 7 min |
| Full Load Runtime (min.) | 2 min |
| Primary UPS Depth (mm) | 185 |
| Primary Form Factor | Desktop |
| Audible Alarm | UPS remains silent in battery backup mode; Alarm sounds only to report low-battery, fault, overload and replace-battery conditions |
| UPS Power Module Dimensions (hwd, in.) | 4.13 x 4.33 x 7.28 |
| Battery Replacement Description | Replaceable internal batteries (see manual) |
| High Voltage Transfer to Battery Power (Setpoint) | 145 |
| Operating Elevation (ft.) | Up to 10,000 ft. |
| DC System Voltage (VDC) | 12 |
| Rated input current (Maximum Load) | 5 A |
| Battery Recharge Rate (Included Batteries) | 6.5 hours (10% to 90%) |
| AC Mode Efficiency Rating (100% Load) | >98% |
| Storage Temperature Range | to +45 degrees Celsius |
| Switches | Switch controls power off/on status |
| UPS Certifications | Tested to UL1778 (USA); Tested to CSA (Canada); Tested to NOM (Mexico); Meets FCC Part 15 Category B (EMI) |
| UPS AC Suppression Response Time | Instantaneous |
| EMI / RFI AC Noise Suppression | Yes |
| Input Circuit Breakers | 5A |
| Cold Start (Startup in Battery Mode During a Power Failure) | Cold-start operation supported |
| Input Phase | Single-Phase |
| WatchDog Compatibility | Supports Watchdog application, OS and hard-reboot restart options for remote applications |
| Communications Cable | DB9 serial interface cable included |
| UPS Certification Details | UL1778: 2014 5th EDITION; CAN/CSA-C22.2 NO. 107.3:2014 3rd EDITION; FCC CLASS B; FCC Part 68 Approved (#5WSWP01B005); Industry Canada Approved (#3449A-005, REN0.1B); RETIE (Colombia) |
| Installation Form Factors Supported with Included Accessories | Tower; Ultra-compact desktop; Wallmount |
| Output Watt Capacity (Watts) | 210 |
| UPS Dataline Suppression | 1 line TEL/DSL or Ethernet |
| Operating Temperature Range | +32 to +104 degrees Fahrenheit / 0 to +40 degrees Celsius |
| Operating Elevation (m) | Up to 3000m |
| Relative Humidity | 0 to 90%, non-condensing |
| Nominal Output Voltage(s) Supported | 110 V, 115 V, 120 V |
| Output Voltage Regulation (Battery Mode) | 120V (±10%) |
| Output Volt Amp Capacity (VA) | 350 |
| Battery Access | Battery access door |
| LED Indicators | 1 Status LED reports operating mode and fault status |
| Output AC Waveform (Battery Mode) | PWM sine wave |
| UPS Input Cord Length (ft.) | 5 |
| Package Contents | Internet Office INTERNET350SER 350VA UPS, INTERNET350SER standby UPS system, DB9 Serial Cable for use with PowerAlert UPS monitoring software, Instruction manual and warranty information |
| Alarm | On Battery |
| Software Included | PowerAlert UPS monitoring software |
| Additional Information | Low voltage transfer to battery power: approx. 100VAC, High voltage transfer to battery power: approx. 141VAC, Cold Start: Inverter can be "cold started" to enable temporary AC output during a power failure |
| Form Factor | Ultra-compact Desk-mount |
| Status Indicators | Line Power, Battery Power Status |
| Typical Battery Recharge Time | 4 hr |
| Maximum Operating Temperature | 122°F |
| Serial Port | Yes |
| Dataline Protection | RJ-11 |
| Load Capacity | 350 VA/180 W |
| Battery Life | 6 yr |
| Waveform Type | Pulse-width Modulated Sine Wave |
| Surge Energy Rating | 316 J |
| UPS Applications | Computer/Peripherals; Retail/Point of Sale; Hospitality |
| Output Capacity (VA) | 350 |
| Package Includes | INTERNET350SER 350VA 210W 120V Standby UPS with 6 Outlets;DB9 serial interface cable;Owner's manual |
| Product Compliance | FCC Part 15 Class B (USA) |
| Product Certifications | RETIE (Colombia); CSA (Canada); CAN/CSA-C22.2 No. 107.3 (Canada); NOM (Mexico); UL 1778 |
| Output Capacity (Watts) | 210 |
| Surge Suppression Rating | 316 J |
| Automatic Voltage Regulation | No Automatic Voltage Regulation |
| Data Line Protection | Includes Data Line Surge Protection |
| External Battery Compatible | Not External Battery Pack Compatible |
| Battery Recharge Time | 6 hr 30 min |
| Power Rating - Real | 210 W |
| Manufacturer Warranty | 3 yr (Limited) |
| Visible Indicator Light Conditions | Fault |
| Operating Temperature - Maximum | 104 deg F |
| Output Ports Included | DB9 Serial |
| Power Cord Length | 5 ft |
| Audible Alarm Conditions | Low Battery, Overload, Replace Battery |
| Operating Temperature - Minimum | 32 deg F |
| Includes Battery | Battery Included |
| Input Current - Maximum | 5 A |
| Package Quantity | 1 |
