2.15" Min Bore Dia
| Thread Type | Internal |
|---|---|
| Hand of Holder | Right Hand |
| Shank Width/Diameter (Decimal Inch) | 1.5000 |
| Toolholder Style | AVRC |
| Insert Compatibility | 14DIR |
| Insert Holding Method | Screw |
| Shank Height (Decimal Inch) | 1.3400 |
| Overall Length (Decimal Inch) | 12.0000 |
| Minimum Bore Diameter (Decimal Inch) | 2.1500 |
| Multi-use Tool | No |
| Back of Bar to Cutting Edge (Decimal Inch) | 45.1500 |
| Neck Diameter (Decimal Inch) | 1.5000 |
| UNSPSC Code | 23291800 |
| Coolant Through | Yes |
| Series | Microscope |
| Country of Origin | Israel |
| MSC Number | MSC# 47723457 |
