3.33" Min Bore Dia
| Thread Type | Internal |
|---|---|
| Hand of Holder | Right Hand |
| Shank Width/Diameter (Decimal Inch) | 2.5000 |
| Toolholder Style | NVRC |
| Insert Compatibility | 5MGIR |
| Insert Holding Method | Screw |
| Shank Height (Decimal Inch) | 2.2800 |
| Overall Length (Decimal Inch) | 11.1200 |
| Minimum Bore Diameter (Decimal Inch) | 3.3300 |
| Multi-use Tool | No |
| Back of Bar to Cutting Edge (Decimal Inch) | 83.1000 |
| Neck Diameter (Decimal Inch) | 2.4900 |
| UNSPSC Code | 23291800 |
| Coolant Through | Yes |
| Series | Megaline |
| Country of Origin | Israel |
| MSC Number | MSC# 47723366 |
