45° Lead Angle
| Minimum Cutting Diameter (mm) | 100.00 |
|---|---|
| Maximum Cutting Diameter (mm) | 100.00 |
| Maximum Depth of Cut (mm) | 4.00 |
| Arbor Hole Diameter (mm) | 32.00 |
| Compatible Insert Size Code | XN U0705 |
| Cutter Style | F2010 |
| Lead Angle | 45 |
| Series | F2010 |
| Overall Height (Decimal Inch) | 50.00 |
| Tool Application | Facing |
| Primary Workpiece Material | Universal |
| Primary Workpiece Material Code | P; S; K; M; N |
| Secondary Workpiece Material | Hard Material |
| Secondary Workpiece Material Code | H; O |
| Standards | ISO |
| UNSPSC Code | 27112803 |
| Coolant Through | No |
| Number Of Cutter Inserts | 7 |
| Number Of Flutes | 7 |
| Country of Origin | Netherlands |
| MSC Number | MSC# 11739844 |
