Takes 5 Inserts, 0° Lead Angle, 95mm High, Through Coolant, Series F2338F-B1
| Maximum Cutting Diameter (Decimal Inch) | 3.3460 |
|---|---|
| Maximum Cutting Diameter (mm) | 85.00 |
| Arbor Hole Diameter (mm) | 32.00 |
| Arbor Hole Diameter (Decimal Inch) | 1.2600 |
| Cutter Style | F2338 |
| Cutting Direction | Right Hand |
| Insert Holding Method | Screw; Clamp |
| Lead Angle | 0 |
| Series | F2338F-B1 |
| Overall Height (Decimal Inch) | 3.7400 |
| Tool Application | Milling |
| Primary Workpiece Material | Cast Iron; Steel |
| Primary Workpiece Material Code | P; K |
| Standards | ISO |
| Cutting Edge Length (Decimal Inch) | 2.7560 |
| UNSPSC Code | 27112803 |
| Toolholder Material | Steel |
| Coolant Through | Yes |
| Number Of Cutter Inserts | 5 |
| Number Of Flutes | 5 |
| Country of Origin | Germany |
| MSC Number | MSC# 47292735 |
