Turning Insert, Round, 4, RCGX, Carbide
| Item | Turning Insert |
|---|---|
| Insert Shape | Round |
| Insert Style | RCGX |
| Inscribed Circle | 4 |
| Insert Size | 120,700 |
| Grade | WIS10 |
| Insert Material | Carbide |
| Insert Application | Roughing |
| Rake | Positive |
| ISO Number | RCGX120700T01020WIS10 |
| Cast Iron (K) Compatibility | No |
| ANSI Number | RCGX45T01020 |
| Non Ferrous (N) Compatibility | No |
| Cutting Direction | Neutral |
| Coating | Uncoated |
| Insert Thickness | 5/16 in |
| Mounting Style | Screw Clamp |
| Steel (P) Compatibility | No |
| Stainless (M) Compatibility | No |
| For Use With | Series SRDCN, SRSCR, PRDCN, PRGCR Holders |
| Relief Angle | 7 Degrees |
| No. of Edges | Variable |
| Hardened (H) Compatibility | No |
| Super Alloy (S) Compatibility | Yes |
| Workpiece Compatibility | Super Alloy (S) |
| Primary Material Application | Titanium, Nickel |
| Primary Material Application ISO Code | S |
| Material | Carbide |
| Package Quantity | 1 |
