Jumper Bar Terminal And Contact Block, 20PK
| Type | Cross-connector |
|---|---|
| Material | PA 66 |
| Number of cross-connected terminals | 10 |
| Approvals | EAC |
| Width (inches) | 0.299 in |
| UL 94 flammability rating | V-0 |
| Storage temperature | 10 deg C |
| Storage temperature, min. | 10 °C |
| Version | For the terminals |
| Type of fixing | when screwed in |
| Continuous operating temp., max. | 130 deg C |
| Rated current, 2-pole | 41 A |
| Storage temperature, max. | 40 deg C |
| Height (inches) | 2.339 in |
| Pitch in mm (P) | 6.1 mm |
| Rated current, multi-pole | 41 A |
| Depth (inches) | 0.709 in |
| Colour | yellow |
| Rated current | 41 A |
| Tightening torque range for fixing screw | 0.5...1.0 Nm |
| Continuous operating temp., min. | -60 deg C |
| Installation advice | Direct mounting |
| Package Quantity | 20 |
