Indexable Face Mill, M370 Series, 1.4990" Max Cut Dia, High Speed Steel, 1.25mm Depth of Cut
| Item | Indexable Face Mill |
|---|---|
| Series | M370 |
| Cutting Dia. | 1.499 in |
| Overall Length | 50 mm |
| Number of Inserts Required | 5 |
| Depth of Cut | 1.25 mm |
| Material - Machining | High Speed Steel |
| Cutting Direction | Right Hand |
| Shank Dia. | 0.8661 in |
| Insert Size | 80412 |
| Arbor Dia. | 22 mm |
| ANSI Code | M370D052Z05WO08 |
| Insert Style | WOEJ SRMH |
| Features | Double-Sided, First Choice for Roughing Applications, High Metal Removal Rates, Six Cutting Edges |
| Insert Holding Type | Screw |
| Rake | -11 Degrees Axial, -12 Degrees Radial |
| Coolant Fed | Coolant Through |
| Number of Inserts | 5 |
| Max. Speed | 28,600 rpm |
| Insert Shape | Trigon |
| Hub Outside Dia. | 44 mm |
| Max. Cutting Dia. | 52 mm |
| Compatible Hardware | Coolant Screw, Hardware Chave Torx DT-9IP, Insert Screw M3x0.5 x 9 IP9 |
| Cutting Application | 3D Profiling, Face Milling, Helical Milling, Plunge Milling, Pocketing, Ramping: Blank, Side and Face Milling, Side/Shoulder Milling: Roughing, Slotting: Square End |
| ISO Number | M370D052Z05WO08 |
| Number of Flutes | 5 |
| Package Quantity | 1 |
