Indexable Face Mill, VSM17 Series, 2" Max Cut Dia, High Speed Steel, 0.6350 in Depth of Cut
| Item | Indexable Face Mill |
|---|---|
| Series | VSM17 |
| Cutting Dia. | 2 in |
| Overall Length | 1.575 in |
| Number of Inserts Required | 5 |
| Depth of Cut | 0.635 in |
| Material - Machining | High Speed Steel |
| Insert Size | 1704 |
| Cutting Direction | Right Hand |
| Shank Shape | Socket Head Cap Screw |
| Shank Dia. | 3/4 in |
| Coolant Fed | Coolant Through |
| Max. Speed | 25,600 rpm |
| Min. Cutting Dia. | 2 in |
| Rake | -6.2 Degrees Radial, 10 Degrees Axial |
| Compatible Hardware | Insert Screw M4x0.7 x 8.4 T15, Torx Wrench TX15 |
| Side Cutting Edge Angle | 0 deg |
| Toolholder Style | XDPT17 |
| ANSI Code | VSM17D200Z05S075XD17 |
| Insert Holding Type | Screw |
| Cutting Application | Face Milling, Helical Milling, Pocketing, Ramping:Blank, Side/Shoulder Milling: Square End, Slotting: Square End |
| Insert Style | XD.T PE R |
| ISO Number | VSM17D200Z05S075XD17 |
| Number of Inserts | 5 |
| Features | Effective Internal Coolant Feature, Increased Ramping Capability, Precisely Reaching the Cutting Edge, Superior Wall and Surface Finish |
| Max. Cutting Dia. | 2 in |
| Number of Flutes | 5 |
| Arbor Dia. | 3/4 in |
| Package Quantity | 1 |
