Indexable Profiling End Mill, VSM17 Series, High Speed Steel, 16.00mm Depth of Cut
| Item | Indexable Profiling End Mill |
|---|---|
| Series | VSM17 |
| Overall Length | 40 mm |
| Depth of Cut | 16 mm |
| Material - Machining | High Speed Steel |
| Cutting Direction | Right Hand |
| Insert Size | 1704 |
| Rake | 12 Degrees Axial, -5.7 Degrees Radial |
| ISO Number | VSM17D063Z06S22XD17 |
| Insert Style | XD.T PE R |
| Insert Holding Type | Screw |
| Features | Effective Internal Coolant Feature, Increased Ramping Capability, Precisely Reaching the Cutting Edge, Superior Wall and Surface Finish Capabilities, True 90 Degrees Capability |
| Cutting Application | Face Milling, Helical Milling, Pocketing, Ramping: Blank, Side and Face Milling, Side/Shoulder Milling: Square End, Slotting: Square End |
| Number of Inserts | 6 |
| ANSI Code | VSM17D063Z06S22XD17 |
| Max. Speed | 22,400 rpm |
| Coolant Fed | Coolant Through |
| Compatible Hardware | Coolant Screw, Insert Screw M4x0.7 x 8.4 T15, Torx Wrench TX15 |
| Side Cutting Edge Angle | 90 deg |
| Arbor Dia. | 22 mm |
| Hub Outside Dia. | 50 mm |
| Package Quantity | 1 |
