Indexable Profiling End Mill, VSM490-10 Series, High Speed Steel, 10.00mm Depth of Cut
| Item | Indexable Profiling End Mill |
|---|---|
| Series | VSM490-10 |
| Overall Length | 40 mm |
| Depth of Cut | 10 mm |
| Material - Machining | High Speed Steel |
| Cutting Direction | Right Hand |
| Insert Size | 100408 |
| Insert Shape | 90 Degrees Rectangle Mill 4 |
| Rake | -8 Degrees Axial, -12.7 Degrees Radial |
| Features | Best-in-Class Wall Finish in Axial Stepping-Down Jobs, Coarse, Lower Cutting Forces and Real Soft Cutting Action, Medium and Fine Pitch Cutter Density Available, Perfect Fit for Taper 40 Spindles and Driven Units, True 90 Degrees Roughing Tool with Embedded Finishing Capability in One Tool |
| ISO Number | VSM490D063Z05S22XN10 |
| ANSI Code | VSM490D063Z05S22XN10 |
| Insert Holding Type | Screw |
| Max. Speed | 19,500 rpm |
| Insert Style | XNGU SRMM |
| Coolant Fed | Coolant Through |
| Number of Inserts | 5 |
| Side Cutting Edge Angle | 90 deg |
| Cutting Application | Face Milling, Side and Face Milling, Side/Shoulder Milling: Square End, Slotting: Square End |
| Compatible Hardware | Anti-Seize Lubricant, Coolant Screw, Hardware Chave Torx DT-9IP, Insert Screw M3x0.5 x 7.2 IP9, Socket Head Screw DIN 912 M10 |
| Arbor Dia. | 22 mm |
| Hub Outside Dia. | 49 mm |
| Package Quantity | 1 |
