Indexable Toolholder, CSDP,
| Item | Indexable Turning Toolholder |
|---|---|
| Insert Shape | Square |
| Overall Length | 6 in |
| Insert Size | 422 |
| Shank | Square |
| Cutting Direction | Neutral |
| Shank Length | 4-5/8 in |
| Cutting Length | 1/2 in |
| Material | Steel |
| Clamp | Top Clamping |
| Rake | -5 Degrees Axial, 0 Degrees Radial |
| Number of Inserts Required | 1 |
| Insert Style | SP |
| Head Length | 1-3/8 in |
| Cutting Application | Facing, Profiling, Turning |
| Toolholder Style | CSDP |
| ISO Number | CSDPN164 |
| Shank Height | 1 in |
| Insert Holding Type | Top Clamping |
| Insert Clearance Angle | 11 deg |
| ANSI Code | CSDPN164 |
| Side Cutting Edge Angle | 45 deg |
| Approach Angle | 45 deg |
| Insert Inscribed Circle | 1/2 in |
| Coolant Fed | Non-Coolant Through |
| Compatible Hardware | 1/16 in Shim Screw, 5/32 in Clamp Screw |
| Shank Width | 1 in |
| Material - Machining | High Speed Steel |
| Lead Angle | 45 Degrees |
| Measurement System | Decimal Inch |
| Package Quantity | 1 |
