NEGATIVE INSERT GEO, 0.281 in, VNMG, 2
| Item | NEGATIVE INSERT GEO |
|---|---|
| Insert Style | VNMG |
| Inscribed Circle | 0.281 in |
| Corner Radius | 2 |
| Rake | Negative |
| ISO Number | VNMG12T308 |
| Cutting Direction | Neutral |
| Included Angle | 35 Degrees |
| Secondary Material Application | Cast Iron, Hardened Steel, Non-Ferrous |
| Primary Material Application | High-Temperature Alloys, Stainless Steel, Steel |
| General Shape | Rhomboid |
| Features | Deformation Resistance |
| Coating Process | PVD |
| Material Grade - Machining | Carbide |
| Thickness | 2.5 |
| Coolant Fed | Non-Coolant Through |
| Insert Holding Type | 3-Part Cycl with 40-60 TaperScrew |
| Primary Material Application ISO Code | P, M, S |
| Depth of Cut | 0.1563 in |
| Measurement System | Decimal Inch |
| Clearance Angle | 0 deg |
| Manufacturer Grade | WU10PT |
| Finish - Machining | TiAlN |
| Number of Cutting Edges | 4 |
| Secondary Material Application ISO Code | K, N, H |
| Through Hole Inside Dia. | 0.1417 in |
| Chip-Breaker Code | Not Applicable |
| Material - Machining | Carbide |
| Shape | Rhomboid |
| ANSI Code | VNMG12T308 |
| Cutting Edge Length | 0.49 in |
| Standards | ANSI, ISO |
| Cutting Application | Finishing |
| Package Quantity | 1 |
