Shell Mill Holders, 1.750" L
| Overall Length | 1-3/4 in |
|---|---|
| Shank Dia. | 1 in |
| Item | Indexable Face Mill |
| Features | Low Cost per Edge |
| Standards | ANSI |
| Arbor Dia. | Not Applicable |
| Depth of Cut | 0.3346 in |
| Max. Cutting Dia. | 3 in |
| Insert Shape | Hexagon 120 |
| Insert Style | Hexagon 120 |
| Coolant Fed | Non-Coolant Through |
| Insert Size | Not Applicable |
| Side Cutting Edge Angle | 56 deg |
| Insert Holding Type | Not Applicable |
| Cutting Direction | Right Hand |
| Package Quantity | 1 |
