1/4 Turn Latch Electrical Enclosures, 24 in H, 6 in D, 24 in W, 12, 13, 3R, 4, 4X
| Item | Electrical Enclosures |
|---|---|
| Nominal Width | 24 in |
| Nominal Height | 24 in |
| Nominal Depth | 6 in |
| NEMA Enclosure Rating | 12, 4, 13, 4X, 3R |
| Enclosure Material | Stainless Steel |
| Closure Method | 1/4 Turn Latch |
| Cover Closure Type | Hinged |
| Knockouts | No |
| Metallic / Non-Metallic | Metallic |
| Color | Silver |
| Finish | Smooth Grained |
| Mounting | Wall |
| Cover Style | Solid with Window |
| Features | Mounting Holes, Poured in Place Gasket, Turn Semi-Flush Latches |
| Standards | CSA Certified, cULus, IEC, UL Listed |
| Solid / Clear Cover | Clear |
| Metal Gauge | 14 ga |
| Enclosure Cover Features | 1/4 Turn Latch, Clear Window |
| Enclosure Cover Type | Hinged |
| Series | Ultimate |
| Enclosure NEMA Rating | NEMA 4X |
| Interior Panel | Mfr No. NP2424C, NP2424CG |
| Material of Enclosure | 304 Stainless Steel |
| Gasket | Seamless Foam-In-Place |
| Usable Opening Depth | 6 in |
| IP Rating | IP66 |
| Capacity | 3,456 cu in |
| Weight | 50 lb. |
| Application | Hubbell Wiegmann N412WSSC ULTIMATE Stainless Steel Series Enclosures are designed to house and protect electrical and electronic components from harsh, dirty environments. For use in installations where dirt, dust, oil, water, or other contaminants are pr |
| Environment - MERCH | Washdown and Corrosion Resistant |
| Includes Knockouts | Knockouts Not Included |
| Compatible Panel Model Number | NP2424C, NP2424CG |
| Body Material Thickness | 14 ga |
| Gasket Material | Seamless Foam-In-Place |
| Package Quantity | 1 |
