Carbon Steel Electrical Enclosures, 16 in H, 8 in D, 16 in W, NEMA 12, Hinged
| CAD Available | Yes |
|---|---|
| Item | Electrical Enclosures |
| Nominal Width | 16 in |
| Nominal Height | 16 in |
| Nominal Depth | 8 in |
| Enclosure NEMA Rating | NEMA 12 |
| Material of Enclosure | Carbon Steel |
| Closure Method | Hasp |
| Enclosure Cover Type | Hinged |
| Knockouts | No |
| Metallic / Non-Metallic | Metallic |
| Color | Gray |
| Finish | Polyester Powder |
| Mounting | Wall |
| Solid / Clear Cover | Solid |
| Features | External Mounting Feet |
| Interior Panel | 31LA18 |
| Metal Gauge | 14 ga |
| Series | N12 |
| Usable Opening Depth | 7.88 in |
| Enclosure Cover Features | Hasp and Staple for Padlocking |
| Gasket | Seamless Polyurethane Poured in Place |
| Standards | CSA Certified, cULus, UL Listed |
| Enclosure Material | Steel |
| Weight | 31 lb. |
| Capacity | 2,048 cu in |
| Application | Intended for use in housing electrical and electronic controls, instruments, components and associated wiring. These enclosures incorporate hinged doors which provide convenient access. Designed for indoor use in protecting components from dust, dirt, oil and water. |
| Gasket Material | Seamless Polyurethane Poured in Place |
| Cover Style | Solid |
| Environment - MERCH | Dust Tight |
| Cover Closure Type | Hinged |
| Includes Knockouts | Knockouts Not Included |
| Body Material Thickness | 14 ga |
| NEMA Enclosure Rating | 12, 13 |
| Compatible Panel Model Number | NP1616, NP1616G |
| Package Quantity | 1 |
