Carbon Steel Electrical Enclosures, 24 in H, 10 in D, 24 in W, NEMA 12, Hinged
| CAD Available | Yes |
|---|---|
| Item | Electrical Enclosures |
| Nominal Width | 24 in |
| Nominal Height | 24 in |
| Nominal Depth | 10 in |
| Enclosure NEMA Rating | NEMA 12 |
| Material of Enclosure | Carbon Steel |
| Closure Method | Hasp |
| Enclosure Cover Type | Hinged |
| Knockouts | No |
| Metallic / Non-Metallic | Metallic |
| Color | Gray |
| Finish | Polyester Powder |
| Mounting | Wall |
| Solid / Clear Cover | Solid |
| Standards | CSA Certified, cULus, UL Listed |
| Metal Gauge | 14 ga |
| Series | N12 |
| Gasket | Seamless Polyurethane Poured in Place |
| Enclosure Cover Features | Hasp and Staple for Padlocking |
| Interior Panel | 2W829 |
| Features | External Mounting Feet |
| Usable Opening Depth | 9.88 in |
| Enclosure Material | Steel |
| Capacity | 5,760 cu in |
| Weight | 52 lb. |
| Application | Intended for use in housing electrical and electronic controls, instruments, components and associated wiring. These enclosures incorporate hinged doors which provide convenient access. Designed for indoor use in protecting components from dust, dirt, oil and water. |
| Gasket Material | Seamless Polyurethane Poured in Place |
| Includes Knockouts | Knockouts Not Included |
| Cover Closure Type | Hinged |
| NEMA Enclosure Rating | 12, 13 |
| Environment - MERCH | Dust Tight |
| Compatible Panel Model Number | NP2424, NP2424G |
| Cover Style | Solid |
| Body Material Thickness | 14 ga |
| Package Quantity | 1 |
