Carbon Steel Electrical Enclosures, 30 in H, 8 in D, 24 in W, NEMA 4, 12, Hinged
| CAD Available | Yes |
|---|---|
| Item | Electrical Enclosures |
| Nominal Width | 24 in |
| Nominal Height | 30 in |
| Nominal Depth | 8 in |
| Enclosure NEMA Rating | NEMA 4, 12 |
| Material of Enclosure | Carbon Steel |
| Closure Method | 1/4 Turn Latch |
| Enclosure Cover Type | Hinged |
| Knockouts | No |
| Metallic / Non-Metallic | Metallic |
| Color | Gray |
| Finish | Polyester Powder |
| Mounting | Wall |
| Solid / Clear Cover | Solid |
| Usable Opening Depth | 7.88 in |
| Interior Panel | 2NJ42, 2NJ43 |
| Enclosure Cover Features | 1/4 Turn Semiflush Latch |
| Metal Gauge | 14 ga |
| IP Rating | IP66 |
| Gasket | Seamless Polyurethane Poured in Place |
| Features | Mounting Holes |
| Series | N412-C |
| Standards | CSA Certified, cULus, IEC, UL Listed |
| Enclosure Material | Steel |
| Application | Hubbell Wiegmann N412C ULTIMATE Series Enclosures are designed to house and protect electrical and electronic components from harsh, dirty environments. For use in installations where dirt, dust, oil, water, or other contaminants are present. Streamlined |
| Cover Closure Type | Hinged |
| Environment - MERCH | Washdown |
| Body Material Thickness | 14 ga |
| Includes Knockouts | Knockouts Not Included |
| Compatible Panel Model Number | NP3024C, NP3024CG |
| Gasket Material | Seamless Polyurethane Poured in Place |
| NEMA Enclosure Rating | 12, 4, 13, 3R |
| Cover Style | Solid |
| Package Quantity | 1 |
