Carbon Steel Electrical Enclosures, 36 in H, 12 in D, 30 in W, NEMA 4, 12, Hinged
| CAD Available | Yes |
|---|---|
| Item | Electrical Enclosures |
| Nominal Width | 30 in |
| Nominal Height | 36 in |
| Nominal Depth | 12 in |
| Enclosure NEMA Rating | NEMA 4, 12 |
| Material of Enclosure | Carbon Steel |
| Closure Method | 1/4 Turn Latch |
| Enclosure Cover Type | Hinged |
| Knockouts | No |
| Metallic / Non-Metallic | Metallic |
| Color | Gray |
| Finish | Polyester Powder |
| Mounting | Wall |
| Solid / Clear Cover | Solid |
| Standards | CSA Certified, cULus, IEC, UL Listed |
| Metal Gauge | 14 ga |
| Usable Opening Depth | 11.88 in |
| Features | Mounting Holes |
| IP Rating | IP66 |
| Gasket | Seamless Polyurethane Poured in Place |
| Series | N412-C |
| Interior Panel | 2NJ48, 2NJ49 |
| Cover Type | Door |
| Enclosure Material | Steel |
| Weight | 91 lb. |
| Capacity | 12,960 cu in |
| Application | Hubbell Wiegmann N412C ULTIMATE Series Enclosures are designed to house and protect electrical and electronic components from harsh, dirty environments. For use in installations where dirt, dust, oil, water, or other contaminants are present. Streamlined |
| Cover Style | Solid |
| Gasket Material | Seamless Polyurethane Poured in Place |
| Includes Knockouts | Knockouts Not Included |
| NEMA Enclosure Rating | 12, 4, 13, 3R |
| Environment - MERCH | Washdown |
| Body Material Thickness | 14 ga |
| Cover Closure Type | Hinged |
| Compatible Panel Model Number | NP3630C, NP3630CG |
| Package Quantity | 1 |
