Enclosure Cover, 11 in. H x 8-1/2 in. W x 4-1/2 in. L, Aluminum
| Item | Enclosure Cover |
|---|---|
| Dimension | 11 in. H x 8-1/2 in. W x 4-1/2 in. L |
| Height | 11 in |
| Width | 8-1/2 in |
| Knockouts | No |
| Type | Enclosure |
| Mounting | External Mounting Plates |
| Material | Aluminum |
| NEMA Enclosure Type | NEMA 4X |
| Application | Designed as an instrument housing or junction box for electrical, electronic, or pneumatic components. It is ideal for applications where a lightweight, corrosion resistant enclosure is required. |
| Depth | 5 in |
| Length | 4-1/2 in |
| Number of Doors (Fixed) | 1 |
| Actual Height | 10-1/2 in |
| Latches Type | Clamps |
| Mounting Type | External Mounting Plates |
| UL Listed | Yes |
| Series | BN4-CHAL |
| Certified Listed | cULus;IEC |
| Actual Depth | 4-1/2 in |
| Each - Width | 8-1/2 in |
| Cubic Capacity | 495 cu in |
| Standard | cULus;IEC |
| Construction | Continuously Welded Seams |
| Listings | UL, CSA |
| Nema Rating | 4X |
| Cover Type | Hinged Cover |
| Actual Width | 8-1/2 in |
| Package Quantity | 1 |
