Full Face Neoprene Flange Gasket for 6" Pipe, 1/16" Thick, No 300
| Pipe Size | 6 in |
|---|---|
| Outside Dia. | 12-1/2 in |
| Inside Dia. | 6-5/8 in |
| Bolt Holes | 12 |
| Thickness | 1/16 in |
| Material of Construction | Neoprene |
| Flange Class | Class 300 |
| Color | Black |
| Item | Full Face Flange Gasket |
| Product Type | Gasket |
| Metal Detectable | No |
| Hardness | Shore 60A |
| Standards | ASME B16.21, ASTM D2000 BC 607 |
| Type | Full Face |
| Temp. Range (F) | -30 Degrees to 250 Degrees |
| Bolt Hole Diameter | 7/8 in |
| For Flange ANSI Class | 300 |
| Binder Material | None |
| Reinforced | Yes |
| Metal Detectable Gasket | No |
| Insert Material | None |
| Included Fasteners | Not Applicable |
| For Fluid Type | Chemicals |
| For Piping System | Food and Beverage |
| Market | Industrial |
| Number of Bolt Holes | 12 |
| FDA Approved | No |
| Resistance Properties | Weather-Resistant |
| Gasket Material | Neoprene |
| System of Measurement | Inch |
| X-Ray Detectable | No |
| Minimum Operating Temperature | -30 deg F |
| Maximum Operating Pressure | 300 psi |
| Inside Diameter | 6-5/8 in |
| For Environment | Beverage, Food |
| Bolt Circle Diameter | 10-5/8 in |
| Gasket Type | Full-Face Gasket |
| Maximum Operating Temperature | 250 deg F |
| For Pipe Size | 6 in |
| Country of Origin (subject to change) | China |
| Package Quantity | 1 |
