O-Ring, PTFE, MSDash 328, PK10
| Dash Number | 328 |
|---|---|
| System of Measurement | Inch |
| Cross Section Shape | Rectangular |
| Cross-Section Shape | Rectangular |
| O-Ring Material | PTFE |
| O-Ring Material Compatibility | Detergents, Water, Carbon Dioxide, Nitrogen, Silicone Grease, Hydraulic Oils, Mineral Oil, Vegetable Oils, Natural Gas, Fatty Acids, Gasoline, Kerosene, Lubricating Oils, Diesel Oil, Hydrochloric Acid, Ethanol, Methanol, Bleach, Toluene, Animal Fats, Liquid, Propane Gas, Acids, Sulfuric, Steam, Acetone, Ammonia, Anhydrous |
| Durometer | 55D |
| Color | White |
| Nominal Inside Dia. | 1-7/8 in |
| Actual Inside Dia. | 1.888 in |
| Nominal Outside Dia. | 1/4 in |
| Item | O-Ring |
| Metal Detectable | No |
| FDA Approved | Yes |
| X-Ray Dectectable | No |
| X-Ray Detectable | No |
| Actual Width | 0.183 in |
| Temp. Range | -100 Degrees to 500 Degrees F |
| Nominal Width | 1/16 in |
| Actual Outside Dia. | 2.254 in |
| Durometer (Hardness) Rating | Very Hard |
| Type | O-Ring |
| Material | PTFE |
| Radius | Not Applicable |
| Cut Type | Split |
| Cross-Section Width | 3/16 in |
| Inside Diameter - Nominal | 1-7/8 in |
| Outside Diameter - Actual | 2-1/4 in |
| Width - Actual | 0.18 in |
| Inside Diameter - Actual | 1.89 in |
| Operating Temperature - Minimum | -100 deg F |
| Outside Diameter - Nominal | 2-1/4 in |
| Operating Temperature - Maximum | 500 deg F |
| Country of Origin (subject to change) | Italy |
| Package Quantity | 10 |
