Square Profile Viton O-Ring, Dash 117, PK10
| Item | O-Ring |
|---|---|
| Dash Number | 117 |
| System of Measurement | Inch |
| Material | Viton |
| Cross Section Shape | Square |
| Cross-Section Shape | Square |
| O-Ring Material | Viton |
| O-Ring Material Compatibility | Detergents, Water, Carbon Dioxide, Nitrogen, Silicone Grease, Hydraulic Oils, Mineral Oil, Vegetable Oils, Natural Gas, Fatty Acids, Gasoline, Kerosene, Lubricating Oils, Diesel Oil, Sulfuric Acid, Hydrochloric Acid, Ethanol, Bleach, Toluene |
| Durometer | 75A |
| Color | Black |
| Nominal Inside Dia. | 13/16 in |
| Actual Inside Dia. | 0.799 in |
| Nominal Outside Dia. | 1 in |
| Metal Detectable | No |
| FDA Approved | No |
| Actual Width | 0.103 in |
| Nominal Width | 3/32 in |
| Temp. Range | -15° to 400° F |
| Application | Standard |
| Durometer (Hardness) Rating | Standard |
| Actual Outside Dia. | 1.005 in |
| X-Ray Detectable | No |
| Type | O-Ring |
| Grade | Standard |
| Properties | High Temperature, Resistant to Chemicals, Resistant to Oils, Resistant to Water, Resistant to Weather |
| Product Type | O-Ring |
| Operating Temperature - Minimum | -15 deg F |
| Cross-Section Width | 3/32 in |
| Inside Diameter - Nominal | 13/16 in |
| Standards | 3A Certified, ISO Certified |
| Operating Temperature - Maximum | 400 deg F |
| Outside Diameter - Actual | 1.005 in |
| Width - Actual | 0.103 in |
| Inside Diameter - Actual | 0.799 in |
| Outside Diameter - Nominal | 1 in |
| Resistance Properties | Chemical-Resistant, High Temperature-Resistant, Oil-Resistant, Water-Resistant |
| Country of Origin (subject to change) | Multiple |
| Package Quantity | 10 |
